View detailsLooking for a reliable Printed Circuit Board Cylinder for PCB Mania Machine? We stock this part for Mania PCB drilling and routing machines as part of our Backup & Entry Boards range. Every unit is checked before dispatch and shipped from Shenzhen, so downtime on your drilling or routing line stays short.
What the Printed Circuit Board Cylinder for PCB Mania Machine Does
Backup boards and entry sheets sit under and on top of the panel stack. They prevent exit burrs, guide the drill tip on entry, cool the bit and improve hole position accuracy.
Product Details
PCB CNC machine parts for mania could be provided such as the pressure foot cup, tool change, pressure foot disk insert with high quality.
Ordering & Delivery
- Trade Term: FOB Shenzhen USD by T/T in advance.
- Discount is allowed against your quantity.
- OED/OEM is accepted.
- Delivery will be carried out by Express or your requirement.
- Lead Time: 2~7 days after payment.
Frequently Asked Questions
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: If machines, it will be about 10~15 working days. If spares, it will be about 2~3 working days after payment.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
When to Replace It
- Exit burrs or entry damage on panels
- Poor hole position accuracy
- Excess drill wear or breakage
- Warped or contaminated boards in stock
How to Confirm Compatibility
Before ordering, please check or send us:
- Board / sheet thickness and size
- Material (wood, melamine, phenolic, aluminium, lubricated)
- Flatness and moisture specification
- Hole size range drilled
Looking for complete machines? See our Drilling & Via Formation.
Technical Questions
When should the Printed Circuit Board Cylinder for PCB Mania Machine be replaced?
Typical signs are: exit burrs or entry damage on panels; poor hole position accuracy; excess drill wear or breakage; warped or contaminated boards in stock.
How fast can the Printed Circuit Board Cylinder for PCB Mania Machine be delivered?
Spare parts in stock usually ship within 2–7 days after payment from Shenzhen, China, by international express (DHL, FedEx, UPS or your own forwarder).
Is the Printed Circuit Board Cylinder for PCB Mania Machine new or refurbished?
The item is supplied in new condition. Every part is inspected before it is packed.
Which machines is the Printed Circuit Board Cylinder for PCB Mania Machine compatible with?
It is designed for Mania PCB drilling and routing machines. Send us the machine model and the original part number (this item: PCB Mania Cylinder) and we will confirm the fit before shipment.
