View detailsThe Hitachi Mark 50 Pressure foot fits Hitachi PCB drilling and routing machines. As a specialist supplier of PCB machine spares, we keep it in our Pressure Feet & Brushes stock and ship it worldwide by express, with technical support to confirm compatibility before you order.
What the Hitachi Mark 50 Pressure foot Does
Pressure feet, bushes and brushes hold the panel flat around the tool and extract chips and dust. A worn foot or brush causes burrs, entry-side damage and poor dust extraction.
Product Details
Anderson Routing BDD Pressure Foot
Ordering & Delivery
- Trade Term: EXW Dongguan USD by T/T in advance.
- Discount is allowed against your quantity.
- OED/OEM is accepted.
- Delivery will be carried out by Express or your requirement.
- Lead Time: 2~7 days after payment.
Frequently Asked Questions
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: If machines, it will be about 10~15 working days. If spares, it will be about 2~3 working days after payment.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
When to Replace It
- Burrs or lifted copper on the entry side
- Dust left on the panel after drilling
- Bristles worn, uneven or melted
- Cracked or deformed foot body
How to Confirm Compatibility
Before ordering, please check or send us:
- Machine brand and spindle model
- Outer diameter and bush hole size
- Brush length and bristle type
- Vacuum fitting compatibility
Looking for complete machines? See our Drilling & Via Formation and Profiling & Routing.
Technical Questions
Is the Hitachi Mark 50 Pressure foot new or refurbished?
The item is supplied in new condition. Every part is inspected before it is packed.
Which machines is the Hitachi Mark 50 Pressure foot compatible with?
It is designed for Hitachi PCB drilling and routing machines. Send us the machine model and the original part number and we will confirm the fit before shipment.
When should the Hitachi Mark 50 Pressure foot be replaced?
Typical signs are: burrs or lifted copper on the entry side; dust left on the panel after drilling; bristles worn, uneven or melted; cracked or deformed foot body.
What information do you need to quote the Hitachi Mark 50 Pressure foot?
Please provide: machine brand and spindle model, outer diameter and bush hole size, brush length and bristle type, vacuum fitting compatibility. Photos of the installed part also help.
Sources & References
- IPC-A-600: Acceptability of Printed Boards
- IPC-6012: Qualification and Performance Specification for Rigid Printed Boards
- Photo Chemical Machining Institute — process capability guidelines
- NIST Engineering Statistics Handbook — process tolerance and capability
Standards are referenced for context. Always confirm parameters against the current published edition and your own process validation.
