Plating & Metallization
Vertical Continuous Plating (VCP) Line, 20 Cells
Engineer-configured plating & metallization equipment for consistent results across rigid, multilayer, and HDI boards.
View detailsThe Pre-Plating Treatment Line (WET-PL-03) handles a defined step in the PCB process flow as part of the plating & metallization group. It is normally specified together with the cells immediately upstream and downstream of it, which is where most of the yield and cycle-time gains actually come from.
Where the Pre-Plating Treatment Line Fits in the Process
In a PCB line the Pre-Plating Treatment Line sits in the plating & metallization area. Correct integration with the steps before and after it is what protects overall yield, cycle time, and cost per panel, so it is specified as part of the wider flow rather than in isolation.
Features and Capabilities
- Designed for low maintenance, fast changeover and high equipment uptime.
- Uniform current distribution for consistent copper thickness and throwing power.
- Filtration and dosing systems to keep bath chemistry within specification.
- Programmable plating cycles for panel and pattern plating.
- Recipe management and process logging via the plc + hmi touchscreen.
Where It Is Used
Used to metallize holes and build copper for multilayer, HDI and heavy-copper boards.
Build and Support
The Pre-Plating Treatment Line is assembled and tested in-house. Electrical, air, water, and exhaust requirements are detailed in the installation drawing issued before delivery. After commissioning we provide process guidance and spares documentation to keep uptime high.
Get a Tailored Quote
Send us your production details and we will configure the Pre-Plating Treatment Line to match, then return a specification and quotation. We are happy to advise on integration with your existing line.
Frequently Asked Questions
What are the utility requirements for the Pre-Plating Treatment Line?
Electrical supply is specified at 3-phase 380-415 V AC, 50/60 Hz. Compressed air, water, and exhaust connections are detailed in the installation drawing supplied before delivery.
What lead time and support come with the Pre-Plating Treatment Line?
Lead time is quoted per order once the configuration is fixed. Installation guidance, commissioning support, and spare-parts documentation are provided so the line reaches stable output quickly.
What is the maximum panel or workpiece size for the Pre-Plating Treatment Line?
This configuration is rated for a maximum panel size of 610 x 610 mm. Larger or thinner stock can usually be accommodated with tooling changes — confirm the exact window for your job before ordering.
Which materials or board types does the Pre-Plating Treatment Line support?
Supported board types include Rigid, multilayer, HDI (flex / rigid-flex optional). Other substrates can often be qualified with a short process trial — send a sample and we will confirm.
