Description

Built for the inspection & quality stage of PCB manufacturing, the Automatic Universal Test Machine (WET-QC-08) is designed to hold consistent quality across rigid, multilayer, and HDI boards. Because it is configured to order, the final build is agreed with our engineers before any quotation is issued.

Line Integration

This inspection & quality system is designed to slot into a conveyorized, automated line or run as a standalone cell. The interfaces to upstream loading and downstream handling are configured so material moves cleanly through the inspection & quality step without bottlenecks.

Design Highlights

  • Defect classification and reporting for SPC and traceability.
  • Fast handling for inline inspection at production speed.
  • Recipe management and process logging via the industrial pc + vision/software.
  • Supplied as automatic (pc/cnc controlled), with options for line integration.
  • Stainless-steel wetted parts and chemically resistant construction where the process requires it.

Common Use Cases

Used for inner-layer and final inspection and electrical test across high-reliability and high-volume production.

Configuration and Ordering

The Automatic Universal Test Machine can be supplied as a standalone unit or built into an automated line. Panel-size handling, control software, throughput, and material compatibility are configured to your production mix. As a configured-to-order system, the specification is finalized with our engineers before quotation.

Enquire About the Automatic Universal Test Machine

Let us know what the Automatic Universal Test Machine needs to do on your line. We will confirm the configuration, throughput, and price, and outline how it integrates with the surrounding stages.

Frequently Asked Questions

What does the Automatic Universal Test Machine do in the production line?
The Automatic Universal Test Machine is configured for a specific stage of the wet-processing or precision-machining sequence. It is usually integrated with the handling and rinse stages around it so that throughput and surface quality stay consistent batch to batch.
Can the Automatic Universal Test Machine be customised for our process?
Yes. Conveyor width, tooling, control options, and the surrounding handling can be adapted to your panel size, throughput target, and facility constraints. Share your specification and we will propose a configuration.
What is the maximum panel or workpiece size for the Automatic Universal Test Machine?
This configuration is rated for a maximum panel size of —. Larger or thinner stock can usually be accommodated with tooling changes — confirm the exact window for your job before ordering.
Which materials or board types does the Automatic Universal Test Machine support?
Supported board types include Rigid, multilayer, HDI (flex / rigid-flex optional). Other substrates can often be qualified with a short process trial — send a sample and we will confirm.

Sources & References

Standards are referenced for context. Always confirm parameters against the current published edition and your own process validation.

D
Reviewed by
Chief Engineer, Wet Etching · WET Etched
Ph.D., Metallurgical & Chemical Engineering, Xiamen University

Technical Parameters

ModelWET-QC-08
Maximum panel size—
Board types supportedRigid, multilayer, HDI (flex / rigid-flex optional)
Automation levelAutomatic (PC/CNC controlled)
Control systemIndustrial PC + vision/software
Throughput30-60 panels/hour
ResolutionLine/space down to 20-30 µm; registration ±15 µm
Power supply3-phase 380-415 V AC, 50/60 Hz
