Description

The VRS Verification and Repair Station (WET-QC-04) is a production-grade inspection & quality system. Rather than a one-size-fits-all unit, it is built to a specification confirmed with your team — panel handling, control software, throughput, and material compatibility are all set to your mix.

Where the VRS Verification and Repair Station Fits in the Process

In a PCB line the VRS Verification and Repair Station sits in the inspection & quality area. Correct integration with the steps before and after it is what protects overall yield, cycle time, and cost per panel, so it is specified as part of the wider flow rather than in isolation.

What It Delivers

  • Fast handling for inline inspection at production speed.
  • Recipe management and process logging via the plc + hmi touchscreen.
  • Supplied as semi-automatic, with options for line integration.
  • Stainless-steel wetted parts and chemically resistant construction where the process requires it.
  • Safety interlocks, alarms and guarding designed for a production environment.

Typical Applications

Used for inner-layer and final inspection and electrical test across high-reliability and high-volume production.

Build and Support

The VRS Verification and Repair Station is assembled and tested in-house. Electrical, air, water, and exhaust requirements are detailed in the installation drawing issued before delivery. After commissioning we provide process guidance and spares documentation to keep uptime high.

Talk to Our Engineers

Every VRS Verification and Repair Station is quoted against a real specification, not a list price. Share your requirements and our engineering team will propose a build and confirm pricing and lead time.

Frequently Asked Questions

Can the VRS Verification and Repair Station be customised for our process?
Yes. Conveyor width, tooling, control options, and the surrounding handling can be adapted to your panel size, throughput target, and facility constraints. Share your specification and we will propose a configuration.
What does the VRS Verification and Repair Station do in the production line?
The VRS Verification and Repair Station is configured for a specific stage of the wet-processing or precision-machining sequence. It is usually integrated with the handling and rinse stages around it so that throughput and surface quality stay consistent batch to batch.
What throughput can the VRS Verification and Repair Station achieve?
Typical throughput is 30-60 panels/hour. Actual figures depend on material thickness, feature density, and the quality target, so treat the rated value as a planning baseline rather than a guarantee.
What lead time and support come with the VRS Verification and Repair Station?
Lead time is quoted per order once the configuration is fixed. Installation guidance, commissioning support, and spare-parts documentation are provided so the line reaches stable output quickly.

Sources & References

Standards are referenced for context. Always confirm parameters against the current published edition and your own process validation.

D
Reviewed by
Chief Engineer, Wet Etching · WET Etched
Ph.D., Metallurgical & Chemical Engineering, Xiamen University

Technical Parameters

ModelWET-QC-04
Maximum panel size—
Board types supportedRigid, multilayer, HDI (flex / rigid-flex optional)
Automation levelSemi-automatic
Control systemPLC + HMI touchscreen
Throughput30-60 panels/hour
ResolutionLine/space down to 20-30 µm; registration ±15 µm
Power supply3-phase 380-415 V AC, 50/60 Hz
